2. Stoichiometry calculation and ternary plot of apatite

pyAp allows users to calculate the stoichiometry and mole fractions of components in apatite using functions ApStoic.py and ApStoic_Ketcham.py.

The stoichiometry calculation method was adapted from Ketcham (2015) https://doi.org/10.2138/am-2015-5171

The results can be plotted in the F-Cl-OH ternary diagram by calling functions in ApThernary.py. See an example below.

Import releavant modules and data

Import modules

import matplotlib.pyplot as plt, pandas as pd, math

## use the 3 lines below if you want to use the pyAp codes inthe subdirectory next to the current path
## comment them, if you want to use the pyAp installed elsewhere on your computer
import os, sys
if not os.path.exists('pyAp') and os.path.exists('../pyAp'): # hack to allow scripts to be placed in subdirectories next to pyAp:
    sys.path.insert(1, os.path.abspath('..'))

## import pyAp modules
from pyAp.ApStoic import stoi_
from pyAp import ApTernary
from pyAp.ApStoic_Ketcham import stoi_ketcham

Import data

data = pd.read_excel('data_ap_major_volatile.xlsx',sheet_name='Sheet2')

Stoichiometry calculation

Use assume_oxy=26 for F- or Cl-apatite; assume_oxy=25 for OH-apatite. The default is 26 if no values are assigned.

results_stoi = stoi_(data,assume_oxy = 26)
results_stoi

	CA	TI	AL	FE	MG	MN	K	NA	CE	SR	P	SI	S	C	XF	XCL	XOH	stoi_bias,(Ca/P-5/3)/(5/3)*100%	sample	CAL_H2O(WT%)
0	10.063423	0.0	0.0	0.046444	0.025872	0.029399	0.0	0.037013	0.013978	0.006038	6.064945	0.001735	0.016931	0.0	0.400665	0.172060	0.427275	0.816762	Ap1c	0.738198
1	9.895894	0.0	0.0	0.046046	0.084643	0.029146	0.0	0.003002	0.012724	0.005986	5.995385	0.044735	0.009942	0.0	0.680179	0.129759	0.190062	-0.059461	Ap2c	0.331212
2	9.941816	0.0	0.0	0.046156	0.088724	0.029216	0.0	0.026175	0.011839	0.006000	5.981111	0.034010	0.009779	0.0	0.682218	0.124887	0.192895	1.079786	Ap3c	0.335344
3	9.917455	0.0	0.0	0.046295	0.090046	0.029305	0.0	0.024756	0.015322	0.006019	6.016471	0.045379	0.014583	0.0	0.559375	0.140459	0.300166	0.017858	Ap4c	0.520263

Use an oxygen number between 25 and 26 using stoi_ketcham() function in module ApStoic_Ketcham.py

results_ketc = stoi_ketcham(data)
results_ketc

	CA	TI	AL	FE	MG	MN	K	NA	CE	SR	...	SI	S	C	XF	XCL	XOH	stoi_bias,(Ca/P-5/3)/(5/3)*100%	sample	CAL_H2O(WT%)	OXYGEN NUMBER
0	9.894319	0.0	0.0	0.045664	0.025437	0.028905	0.0	0.036391	0.013743	0.005936	...	0.001706	0.016647	0.0	0.393932	0.169168	0.436899	0.816762	Ap1c	0.767726	25.563101
1	9.821228	0.0	0.0	0.045698	0.084005	0.028926	0.0	0.002980	0.012628	0.005941	...	0.044397	0.009867	0.0	0.675047	0.128780	0.196173	-0.059461	Ap2c	0.344460	25.803827
2	9.865694	0.0	0.0	0.045803	0.088045	0.028993	0.0	0.025975	0.011749	0.005954	...	0.033750	0.009705	0.0	0.676994	0.123931	0.199075	1.079786	Ap3c	0.348758	25.800925
3	9.799792	0.0	0.0	0.045746	0.088978	0.028957	0.0	0.024462	0.015140	0.005947	...	0.044841	0.014410	0.0	0.552738	0.138793	0.308469	0.017858	Ap4c	0.541074	25.691531

4 rows × 21 columns

## difference in H2O concentration calculated using 26 oxygen, and oxygen number between 25 and 26
results_stoi["CAL_H2O(WT%)"]-results_ketc["CAL_H2O(WT%)"]

0   -0.029528
1   -0.013248
2   -0.013414
3   -0.020811
Name: CAL_H2O(WT%), dtype: float64

The calculated oxygen number should fall between 25 and 26

results_ketc['OXYGEN NUMBER']

0    25.563101
1    25.803827
2    25.800925
3    25.691531
Name: OXYGEN NUMBER, dtype: float64

Plot apatite on F-Cl-OH ternary diagram

Plot F-Cl-OH mole fractions calculated above

# set up a figure for ternary plot (e.g. figure with 2 subplots)
fig, (ax1, ax2) = plt.subplots(1,2,figsize=(12, 6))

# set up blank ternary digram for each axis
ApTernary.ternary(ax1)
ApTernary.ternary(ax2)

for idx, value in results_stoi.iterrows():
    x_f = value['XF']
    x_cl = value['XCL']
    x = (x_f + x_cl/2) * 100
    y = x_cl*math.sqrt(3)*50

    if x > 100:
        x = 100
    if y > math.sqrt(3)*50:
        y = math.sqrt(3)*50

    ax1.plot(x,y,'o',ms=10,label=value['sample'])

for idx, value in results_ketc.iterrows():
    x_f = value['XF']
    x_cl = value['XCL']
    x = (x_f + x_cl/2) * 100
    y = x_cl*math.sqrt(3)*50

    if x > 100:
        x = 100
    if y > math.sqrt(3)*50:
        y = math.sqrt(3)*50

    ax2.plot(x,y,'*',ms=10,label=value['sample'])

ax1.axis('off')
ax1.legend(loc='best')
plt.show()

save results

results_stoi.to_csv("stoichiometry_26O.csv")
results_ketc.to_csv("stoichiometry_VariedO.csv")
